Question

Draw a logic circuit which represents the following logic expression:

X = NOT (A AND B) OR (A AND NOT B)​

Answer 1

Attached image

Step-by-step explanation:

Step 1/4

1. First, we need to create a circuit for (A AND B). We can use an AND gate for this purpose, with inputs A and B.

Step 2/4

2. Next, we need to create a circuit for NOT (A AND B). We can use a NOT gate connected to the output of the AND gate from step 1.

Step 3/4

3. Now, we need to create a circuit for (A AND NOT B). We can use another AND gate with inputs A and the output of a NOT gate connected to input B.

Step 4/4

4. Finally, we need to create a circuit for the entire expression X = NOT (A AND B) OR (A AND NOT B). We can use an OR gate with inputs from the outputs of the NOT gate in step 2 and the AND gate in step 3. So, yes, it is possible to create a logic circuit that represents the given logic expression. The circuit would consist of 2 AND gates, 2 NOT gates, and 1 OR gate.
